OUR PROJECT
Before connecting any devices you first have to download an updated driver, which can be found at http://www.bluesoleil.com/download/
To begin with you must first plug in the BAM module into the Create iRobot and the Bluesoleil Bluetooth receiver to the computer. Once both are connected you have to enter My Bluetooth places and find what outgoing port is connected to the iRobot. Take that information into the Basic code in order to make sure the program connects to the correct COM port and the two items will link. Run the VB code and click open com port. Finally, enjoy your experience.
Here is the code for our program. (be prepared to scroll for awhile)
Public Forward_speed, Backward_speed, Forward_more, Backward_more, Left_turn, Right_turn As Integer
Private Declare Sub Sleep Lib "kernel32" (ByVal dwMilliseconds As Long)
Private Sub Command1_Click()
Dim hb(28) As Byte 'Happy Birthday Notes [SONG #0]
Dim hbd(30) As Byte 'Happy Birthday Notes [Song #1]
Dim play(4) As Byte 'Plays song
Dim plays(4) As Byte 'Plays rest of song
' 1st part of happy birthday (limit is 16 notes)
hb(0) = 128
hb(1) = 140
hb(2) = 0
hb(3) = 12
hb(4) = 60
hb(5) = 16
hb(6) = 60
hb(7) = 16
hb(8) = 62
hb(9) = 32
hb(10) = 60
hb(11) = 32
hb(12) = 65
hb(13) = 32
hb(14) = 64
hb(15) = 50
hb(16) = 60
hb(17) = 16
hb(18) = 60
hb(19) = 16
hb(20) = 62
hb(21) = 32
hb(22) = 60
hb(23) = 32
hb(24) = 67
hb(25) = 32
hb(26) = 65
hb(27) = 50
buffer = hb
MSComm1.Output = buffer
play(0) = 128
play(1) = 132
play(2) = 141
play(3) = 0
buffer = play
MSComm1.Output = buffer
Sleep (5000)
'2nd part of happy birthday
hbd(0) = 128
hbd(1) = 140
hbd(2) = 1
hbd(3) = 13
hbd(4) = 60
hbd(5) = 16
hbd(6) = 60
hbd(7) = 16
hbd(8) = 72
hbd(9) = 32
hbd(10) = 69
hbd(11) = 32
hbd(12) = 65
hbd(13) = 32
hbd(14) = 64
hbd(15) = 32
hbd(16) = 62
hbd(17) = 60
hbd(18) = 71
hbd(19) = 16
hbd(20) = 71
hbd(21) = 16
hbd(22) = 69
hbd(23) = 32
hbd(24) = 65
hbd(25) = 32
hbd(26) = 67
hbd(27) = 32
hbd(28) = 65
hbd(29) = 50
buffer = hbd
MSComm1.Output = buffer
plays(0) = 128
plays(1) = 132
plays(2) = 141
plays(3) = 1
buffer = plays
MSComm1.Output = buffer
End Sub
Private Sub Done_Click()
End Sub
Private Sub Exit_Click()
If MSComm1.PortOpen Then MSComm1.PortOpen = False
Unload Me
End Sub
Private Sub Form_Load()
Forward_more = 0
Backward_more = 129
Right_turn = 5
Left_turn = 255
End Sub
'------------------------------------------------
'---------------Port Commands--------------------
'------------------------------------------------
Private Sub open_Click()
MSComm1.CommPort = 1 'DO NOT FORGET
' 56000 baud, no parity, 8 data, and 1 stop bit.
MSComm1.Settings = "56000,N,8,1"
'define input buffer size when data incoming
MSComm1.InputLen = 0
MSComm1.RThreshold = 2
' Open the port.
MSComm1.PortOpen = True
If (MSComm1.PortOpen) Then
Console.Text = "Port is Open for Business"
Else
Console.Text = "Port is Closed"
End If
End Sub
Private Sub close_Click()
If MSComm1.PortOpen Then MSComm1.PortOpen = False
Console.Text = "This Port is Closed!"
End Sub
'------------------------------------------------
'--------------Move Commands---------------------
'------------------------------------------------
Private Sub Forward_Click()
Dim f(7) As Byte 'move forward array of 7 bytes
Backward_more = 129
Left_turn = 255
Right_turn = 5
f(0) = 128
f(1) = 130
f(2) = 137
f(3) = 0
f(4) = 55
f(5) = 128
f(6) = 0
buffer = f
MSComm1.Output = buffer
End Sub
Private Sub fastforward_Click()
Backward_more = 129
Left_turn = 255
Right_turn = 5
If (Forward_more = 128) Then
Forward_more = 128
Else
Forward_more = Forward_more + 1
End If
Dim f(7) As Byte 'move forward array of 7 bytes
f(0) = 128
f(1) = 130
f(2) = 137
f(3) = Forward_more
f(4) = 55
f(5) = 128
f(6) = 0
buffer = f
MSComm1.Output = buffer
End Sub
Private Sub Backward_Click()
Dim b(7) As Byte 'move backward array of 7 bytes
Forward_more = 0
Left_turn = 255
Right_turn = 5
b(0) = 128
b(1) = 130
b(2) = 137
b(3) = 255
b(4) = 64
b(5) = 128
b(6) = 0
buffer = b
MSComm1.Output = buffer
End Sub
Private Sub fastback_Click()
Dim b(7) As Byte 'move backward array of 7 bytes
Forward_more = 0
Left_turn = 255
Right_turn = 5
If (Backward_more = 255) Then
Backward_more = 255
Else
Backward_more = Backward_more + 1
End If
b(0) = 128
b(1) = 130
b(2) = 137
b(3) = Backward_more
b(4) = 64
b(5) = 128
b(6) = 0
buffer = b
MSComm1.Output = buffer
End Sub
Private Sub Left_Click()
Dim L(7) As Byte 'move left array of 7 bytes
L(0) = 128
L(1) = 130
L(2) = 137
L(3) = 0
L(4) = 255
L(5) = 0
L(6) = 0
buffer = L
MSComm1.Output = buffer
End Sub
Private Sub veerleft_Click(Index As Integer)
Dim f(7) As Byte 'move forward array of 7 bytes
Right_turn = 5
If (Left_turn = 5) Then
Left_turn = 5
Else
Left_turn = Left_turn - 50
End If
f(0) = 128
f(1) = 130
f(2) = 137
f(3) = Forward_more
f(4) = 55
f(5) = 1
f(6) = Left_turn
buffer = f
MSComm1.Output = buffer
End Sub
Private Sub Right_Click()
Dim r(7) As Byte 'move right array of 7 bytes
r(0) = 128
r(1) = 130
r(2) = 137
r(3) = 0
r(4) = 255
r(5) = 255
r(6) = 255
buffer = r
MSComm1.Output = buffer
End Sub
Private Sub veerright_Click(Index As Integer)
Dim f(7) As Byte 'move forward array of 7 bytes
Left_turn = 255
If (Right_turn = 255) Then
Right_turn = 255
Else
Right_turn = Right_turn + 50
End If
f(0) = 128
f(1) = 130
f(2) = 137
f(3) = Forward_more
f(4) = 75
f(5) = 255
f(6) = Right_turn
buffer = f
MSComm1.Output = buffer
End Sub
Private Sub Stop_Click()
Dim stp(7) As Byte 'stop moving array of 7 bytes
stp(0) = 128
stp(1) = 130
stp(2) = 137
stp(3) = 0
stp(4) = 0
stp(5) = 0
stp(6) = 0
buffer = stp
MSComm1.Output = buffer
End Sub
'------------------------------------------------
'-------------Other Fancy Commands---------------
'------------------------------------------------
Private Sub LightOn_Click()
Dim ind(6) As Byte 'Indicator light array of 6 bytes
Dim ok As Boolean
ind(0) = 128
ind(1) = 132
ind(2) = 139
ind(3) = 2
ind(4) = 0
ind(5) = 0
buffer = ind
MSComm1.Output = buffer
End Sub
Here are some of the resources we used to work on our project.
- http://compsci.snc.edu/cs460/cohejr/
- http://www.sparkfun.com/commerce/product_info.php?products_id=684
- http://www.robotics.utexas.edu/rrg/learn_more/low_ed/types/industrial.html
- http://realterm.sourceforge.net/
- http://irobotcreate.googlepages.com/
